Seagate Barracuda 3.5 inch HDD 4TB 256MB

1 / 2
SeagateBrand: Seagate
No reviews yetWrite a review
Model
BarraCuda 3.5 inch HDD 4TB
MPN
ST4000DM004
EAN
763649094402
Price on request
Seagate BarraCuda: BarraCuda 3.5 inch HDD 4TB
BarraCuda 3.5 inch HDD 2TB 256MB 5400rpmOut of stockSeagate BarraCuda 3.5 inch HDD 2TB 256MB 7200rpmOut of stockSeagate BarraCuda 3.5 inch HDD 3TB 256MB 5400rpmOut of stockSeagate BarraCuda 3.5 inch HDD 500GB 32MB 7200rpmOut of stockSeagate BarraCuda 3.5 inch HDD 6TB 256MB 5400rpmOut of stockSeagate BarraCuda 3.5 inch HDD 8TB 256MB 5400rpmOut of stockBarraCuda 3.5 inch HDD 4TBOut of stockSeagate BarraCuda HDD 1TB 64mbOut of stock

Key features

  • Type: HDD (Hard Disk)
  • Interface: SATA
  • Form Factor: 3.5 inch
  • Capacity: 4 TB

From the manufacturer





Product information

Technical Details

Seagate Barracuda 4TB 5400 RPM Desktop Internal Hard Drive ST4000DM004


Overview :

  • Compliant with RoHS requirements in China and Europe.
  • High instantaneous (burst) data-transfer rates (up to 600MB per second).
  • Native Command Queuing with command ordering to increase performance in demanding applications.
  • Quiet operation.
  • SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
  • State-of-the-art cache and on-the-fly error-correction algorithms.
  • Support for S.M.A.R.T. drive monitoring and reporting.
  • Supports latching SATA cables and connectors.
  • TGMR recording technology provides the drives with increased areal density.
  • Worldwide Name (WWN) capability uniquely identifies the drive.



Specification :

Formatted capacity (512 bytes/sector)**4000GB (4TB)
Guaranteed sectors7,81,40,37,168
Heads4
Disks2
Bytes per sector4096
Default sectors per track63
Default read/write heads16
Default cylinders16,383
Recording density (max)2294 kB/in
Track density (avg)540 ktracks/in
Areal density (avg)1203 Gb/in
SATA interface transfer rate600 MB/s
Maximum data transfer rate190 MB/s
ATA data-transfer modes supportedPIO modes: 0 to 4
 Multiword DMA modes: 0 to 2
 Ultra DMA modes 0 to 6
Cache buffer256MB
Height (max)20.17mm / 0.794 in
Width (max)101.6mm (± 0.25) / 4.0 in (± 0.010)
Length (max)146.99mm / 5.787 in
Weight (typical)490g / 1.08 lb
Average latency6.0 ms
Power-on to ready (typ)10.0s
Standby to ready (typ)10.0s
Startup current (typical) 12V2.0A
Voltage tolerance (including noise)5V ±5%
 12V ±10%
Non-Operating (Ambient °C)–40° to 70°
Operating ambient temperature (min °C)0°
Operating temperature (drive case max °C)60°
Temperature gradient20°C per hour max (operating)
 30°C per hour max (non-operating)
Relative humidity5% to 90% (operating)
 5% to 95% (non-operating)
Relative humidity gradient (max)30% per hour
Wet bulb temperature (max)30°C max (operating)
 40°C max (non-operating)
Altitude, operating–304m to 3048m
 (–1000 ft to 10,000 ft)
Altitude, non-operating–304m to12,192m
(below mean sea level, max)(–1000 ft to 40,000+ ft)
Operational shock (max)80 Gs (read) / 70 Gs (write) at 2ms
Non-operational shock (max)300 Gs at 2ms
Vibration, operating10Hz to 22Hz: 0.25 Gs, Limited displacement
 22Hz to 350Hz: 0.50 Gs
 350Hz to 500Hz: 0.25 Gs
Vibration, non-operating5Hz to 22Hz: 3.0 Gs
 22Hz to 350Hz: 3.0 Gs
 350Hz to 500Hz: 3.0 Gs
Idle2.2 bels (typical)
 2.4 bels (max
Seek2.4 bels (typical)
 2.7 bels (max)
Non-recoverable read errors1 per 1015bits read
Load/unload cycles600,000 at 25°C, 50% rel. humidity
Warranty2 Years
