- Brand: ASUS
- Model: ROG XREAL R1
- UPC: 199291465084
- MPN: 90LJ00M5-B01670
-
240Hz Refresh Rate with 0.01ms Response Time: Micro‑OLED FHD (1920 × 1080) gaming glasses deliver ultra‑low latency and exceptionally smooth, responsive gameplay
-
57° Expanded Field of View for Immersive Visuals: Projects a 171‑inch virtual screen at 4 meters, covering 95% of the focused viewing area for a truly immersive experience
-
Native 3DoF with Electrochromic Lenses: Supports Anchor Mode and Follow Mode. Anchor Mode enables automatic transparency, while three manually adjustable electrochromic tint levels provide visual comfort across different lighting conditions.
-
Electrochromic Lens Technology: 3 tint levels to adapt to changing lighting conditions for optimal visual comfort.
-
Instant 3D: Transforms standard 2D content into immersive 3D effect for enhanced depth and realism
-
Audio Sound by Bose: Enhances spatial awareness and deepens in‑game immersion with rich, detailed sound
-
Seamless Connected & Controlled: USB‑C plug‑and‑play connectivity with deep ROG Ally integration, allowing Ally to directly control the glasses.
-
ROG Control Dock Compatibility: Features HDMI® and DisplayPort™ connectivity to ensure seamless compatibility with PCs and gaming consoles
Ask a Question About This Product
ROG XREAL R1
240Hz Micro-OLED Gaming AR Glasses with 171-inch Virtual Display
The ROG XREAL R1 is a premium gaming AR glasses solution built for immersive handheld gaming, console play, PC gaming and portable entertainment. Featuring Sony Micro-OLED displays, 1920 x 1080 resolution per eye, up to 240Hz refresh rate with Frame Rate Boost, 0.01ms response time, 57° field of view, electrochromic dimming, Native 3DoF tracking, Instant 3D and Sound by Bose, it turns your connected device into a large-screen personal gaming experience.
Key Highlights
A premium AR gaming display system designed for ultra-smooth visuals, portable big-screen gaming, spatial audio and ROG ecosystem connectivity.
240Hz Refresh
Up to 240Hz refresh rate with Frame Rate Boost for smoother gameplay.
0.01ms Response
Ultra-fast panel response time for crisp and responsive visuals.
Sony Micro-OLED
FHD Micro-OLED display technology with 1920 x 1080 pixels per eye.
Virtual Screen
Projects up to a 171-inch virtual screen at 4 meters.
Wide FOV
57-degree expanded field of view for immersive visual coverage.
Native Tracking
Native 3DoF support with Anchor Mode and Follow Mode.
Instant 3D
Transforms compatible 2D content into an immersive 3D effect.
Sound by Bose
Integrated speaker audio tuned for richer gaming immersion.
Personal Big-Screen Gaming, Anywhere
ROG XREAL R1 is designed for gamers who want a large-screen visual experience without carrying a full monitor. It projects up to a 171-inch virtual screen at 4 meters, giving handheld consoles, gaming laptops, PCs and compatible USB-C devices a more immersive private display setup.
Ultra-Portable Gaming Display
Enjoy a private large-screen gaming experience from a compact AR glasses form factor, ideal for handheld gaming, travel, dorm rooms, compact desks and personal entertainment.
Sony Micro-OLED Visual Quality
The ROG XREAL R1 uses Sony Micro-OLED display technology with 1920 x 1080 resolution per eye, 700 nits maximum brightness, 106% sRGB color gamut and 40 PPD pixel density. It is engineered to deliver vivid colors, sharp detail and responsive motion in a compact AR display format.
FHD Per-Eye Resolution
Each eye receives a 1920 x 1080 Micro-OLED image, creating a sharp and immersive viewing experience for games, videos and connected-device display output.
High Brightness and Wide Color
With up to 700 nits maximum brightness and 106% sRGB color gamut, the ROG XREAL R1 is designed to deliver bright, vibrant and detailed visuals across gaming and entertainment content.
1920 x 1080
Full HD resolution per eye for sharp AR display output.
700 nits Max
High peak brightness for clear visual presentation.
106% sRGB
Wide sRGB color coverage for vivid gaming visuals.
40 PPD
40 pixels per degree for detailed virtual screen clarity.
Smooth 240Hz Gaming with Ultra-Low Response
Built for gaming, ROG XREAL R1 supports 120Hz refresh rate and up to 240Hz when Frame Rate Boost is enabled. With 0.01ms panel response time and 3ms motion-to-photon latency, it is designed for smooth, responsive gameplay across compatible devices.
Up to 240Hz Frame Rate Boost
Frame Rate Boost mode enables up to 240Hz refresh rate for users who want exceptionally smooth motion in supported gaming scenarios.
0.01ms Response and 3ms MTP Latency
The fast Micro-OLED panel response and low motion-to-photon latency help improve responsiveness during fast-paced games, action titles and competitive play.
57° Field of View and 171-inch Virtual Screen
The 57° expanded field of view covers more of your focused viewing area, helping the virtual display feel larger and more immersive. ASUS lists a virtual screen size of up to 171 inches at 4 meters, making it suitable for cinematic gaming and entertainment.
Immersive AR Viewing Experience
The wide field of view and large virtual screen create an immersive private display experience for gaming, movies and productivity-style extended-screen usage.
Native 3DoF with Anchor and Follow Modes
ROG XREAL R1 includes Native 3DoF environment understanding, allowing the virtual screen to behave more naturally during use. Anchor Mode can keep the virtual screen fixed in space, while Follow Mode keeps the display aligned with your head movement for a simpler mobile viewing experience.
Anchor Mode
Anchor Mode helps keep the virtual display positioned in a fixed space, improving comfort when users want a monitor-like viewing position.
Follow Mode
Follow Mode keeps the virtual display with your head movement, making it useful for mobile gaming, travel and quick plug-and-play usage.
Electrochromic Dimming for Better Comfort
The built-in electrochromic dimming system provides three manually adjustable tint levels, helping the lenses adapt to different lighting environments. ASUS also lists auto transparency in Anchor Mode, improving comfort and usability when switching between virtual display and real-world awareness.
Electrochromic Lens
Adjustable tint technology helps improve visual comfort.
3 Tint Levels
Three manually adjustable tint levels for different lighting conditions.
Auto Transparency
Auto transparency support is available in Anchor Mode.
Eye Comfort
TÜV flicker-free, low blue light and Eye Comfort AR certifications.
Instant 3D and Immersive Audio by Bose
ROG XREAL R1 supports Instant 3D and 3D mode, transforming compatible 2D content into a more immersive 3D effect. Integrated speakers with Sound by Bose help enhance spatial awareness and gaming immersion, while the microphone array with noise cancelling supports communication and voice use.
Instant 3D Experience
Instant 3D helps add depth and realism to supported content, making games, videos and compatible media feel more immersive.
Sound by Bose
Built-in speakers tuned with Bose audio help deliver richer sound directly from the glasses, reducing the need for separate speakers during casual gaming or entertainment.
ROG Ecosystem Connectivity and Control Dock
ROG XREAL R1 is designed for seamless ROG ecosystem usage, including deep integration with ROG Ally. USB-C plug-and-play connectivity with DisplayPort Alt Mode enables direct connection with compatible devices, while the ROG Control Dock expands compatibility for gaming PCs and consoles.
ROG Control Dock Included
The ROG Control Dock adds dedicated controls and broader connection flexibility, including GamePlus, Game Visual and HDR10 compatibility support.
Console and PC Friendly
The Control Dock provides display connectivity options for wider gaming device compatibility, making it useful for PCs, consoles and ROG handheld setups.
Lightweight Design with Gaming Comfort Features
At just 0.09kg net weight, ROG XREAL R1 is designed for long gaming and entertainment sessions without the bulk of a traditional monitor. Adjustable temple angles, included nose pads and a detachable prescription lens frame help improve comfort and fit.
Portable Gaming AR Setup
The included carrying case helps protect the glasses during travel, making the ROG XREAL R1 suitable for gamers who want a portable large-screen experience on the move.
0.09kg Net Weight
Lightweight AR glasses design for portable use.
Temple Adjustment
Three temple angle adjustment levels for better comfort.
Aura RGB
ROG gaming styling with Aura RGB support.
Prescription Frame
Detachable prescription lens frame included in the accessory list.
Ideal Use Cases
ROG XREAL R1 is built for gamers and mobile entertainment users who want a portable big-screen display without a traditional monitor. It is especially useful for ROG Ally users, handheld gaming, console gaming, laptop gaming and private movie viewing.
ROG Ally Gaming
Designed for deep ROG Ally ecosystem connectivity and control.
PC Gaming
Use with compatible PCs through USB-C or Control Dock connectivity.
Console Gaming
Control Dock support helps expand console gaming compatibility.
Private Cinema
Enjoy movies and streaming on a large private virtual screen.
Travel Entertainment
Portable design for gaming and content viewing while travelling.
3D Content
Instant 3D support for compatible immersive media experiences.
Compact Desks
Large virtual screen experience without needing a physical monitor.
Private Viewing
Personal display experience for focused gaming and entertainment.
Specification Overview
| Product Name | ROG XREAL R1 |
|---|---|
| Product Type | Gaming AR Glasses |
| Display Technology | Sony Micro OLED |
| Panel Size | 0.55-inch |
| Resolution | 1920 x 1080 pixels per eye |
| Refresh Rate | 120Hz, up to 240Hz with Frame Rate Boost On |
| Panel Response Time | 0.01ms |
| Motion-to-Photon Latency | 3ms |
| Brightness | 700 nits max |
| Color Gamut | 106% sRGB |
| Field of View | 57° |
| Virtual Screen Size | Up to 171 inches at 4 meters |
| Instant 3D | Yes |
| 3D Mode Support | Yes |
| Electrochromic Dimming | Yes, 3 tint levels |
| Auto Transparency | Yes, in Anchor Mode |
| PPD | 40 pixels per degree |
| Sensor | Capacitive sensor |
| Environment Understanding | Native 3DoF |
| Speaker | Yes, Sound by Bose |
| Microphone | Mic-array with noise-cancelling |
| Audio Technology | Phase cancellation |
| Main I/O Port | 1 x USB Type-C with DisplayPort Alt Mode |
| Temple Angle Adjustment | 3 levels |
| Aura RGB | Yes |
| Physical Dimensions | 15.3 x 4.9 x 16.6 cm |
| Box Dimensions | 27.1 x 16.1 x 15.7 cm |
| Net Weight | 0.09 kg |
| Gross Weight | 1.360 kg |
| Certifications | TÜV Flicker Free, TÜV Low Blue Light hardware solution, TÜV Eye Comfort AR, FSC MIX |
| Control Dock Features | GamePlus, Game Visual, HDR10 compatibility |
| Control Dock Dimensions | 21.5 x 2.5 x 10 cm |
| Control Dock Weight | 0.23 kg |
| Control Dock I/O | 1 x USB Type-C Data + Power, 1 x USB Type-C DC-IN / 5V, 1 x USB Type-C DP Alt Mode front, 1 x DisplayPort |
| IPD Support | R1-N: 57-66mm, R1-B: 66-75mm |
| Accessories | Carrying case, USB-C cable, warranty card, QSG, cleaning cloth, detachable prescription lens frame, nose pads, ROG Control Dock, 2 x USB-A to USB-C cable |
| Best For | ROG Ally gaming, PC gaming, console gaming, handheld gaming, private entertainment, travel display and immersive AR viewing |
FAQ
What is ROG XREAL R1?
ROG XREAL R1 is a pair of gaming AR glasses designed to create a large virtual display experience for compatible handhelds, PCs, consoles and USB-C devices.
What display technology does it use?
It uses Sony Micro-OLED display technology with 1920 x 1080 resolution per eye.
Does it support 240Hz refresh rate?
Yes. The official specification lists 120Hz refresh rate and up to 240Hz when Frame Rate Boost is enabled.
How large is the virtual screen?
ASUS lists a virtual screen size of up to 171 inches at 4 meters.
Does it support 3D content?
Yes. ROG XREAL R1 supports Instant 3D and 3D mode.
Does it include built-in audio?
Yes. It includes speakers with Sound by Bose and a mic-array with noise-cancelling.
Is the ROG Control Dock included?
The official accessory list includes the ROG Control Dock, but final bundle contents can vary by region. Please verify the final box contents before purchase.
Take ROG Gaming to a Personal 171-inch Virtual Display
Choose the ROG XREAL R1 for an immersive gaming AR glasses experience with Sony Micro-OLED visuals, up to 240Hz refresh rate, 0.01ms response, Native 3DoF, Instant 3D, Sound by Bose and ROG Control Dock connectivity.
